Humminbird 900 Series Sonar - $999.99 to $1499.99

The Humminbird 900 Series Sonar is built around a widescreen format, giving the serious angler a huge on-the-water performance advantage. With a 16:9 aspect ratio display for easy-to-read whole screen or split screen viewing, the Humminbird 900 Series will put you on the fish.

Dual Beam PLUS: Get the best of both worlds, with selectable narrow and wide beams you can view individually, or melded into one display. Features precision, 20-degree beam that is optimized for excellent bottom detail, and reveals fish hidden in bottom clutter, along with wider, 60-degree beam provides greater coverage for fish and baitfish. Beams may be viewed separately, side-by-side, or blended together for the most complete picture. 1x depth-bottom coverage allows you to find fish and structure in an area equal to your depth.

Optional QuadraBeam PLUS: provides full 90-degree; coverage from side-to-side or directly below. DualBeam PLUS 60-degree and 20-degree beams scan below the boat and two fan-shaped 35-degree beams look to the sides, to shows whether fish are to the right, left or below the boat for cast placement. Unique display shows you two separate views, below and to the sides. Scans an area equal to twice your depth, revealing more fish and structure.

Side Imaging Sonar: Offering amazingly clear, picture-like images of fish, the bottom and structure, it is the ultimate structure-finding tool. Its massive coverage - 480ft from side-to-side (240ft in each direction) - allows you to scan in mere minutes what used to take hours. Its high frequency sonar (not a camera) cuts through murk with crystal clarity. (Select models only - see chart below)

Down Imaging Sonar: Humminbird pointed their Side Imaging technology in a new direction - straight down. Now you can see the detail of what is happening below your boat.  Timber, brush, bridge pilings, rocks and any other structure will pop with stunning detail as you patrol the water. (Available on select models only - see chart below)

50-Channel GPS: With trackplotting, chartplotting, GPS speed, and Humminbird ContourXD, which is an enhanced professional mapping package with over 3,000 U.S. Lake Maps in its database. You will be able to find a lake close to any location you may want to wet a line. As an added bonus, it also features depth contour lines, so you can find all the drops, bumps and channels holding fish. Includes U.S. lights/markers, and major roads and interstates.

Additional advanced sonar features and user-friendly technology include: Freeze-Frame with ability to mark structure on Sonar, Instant Image Update, Real Time Sonar RTS Window, Selective Fish ID, Sonar Echo Enhancement, Sonar Recording, Sonar Snapshot, Split Screen Zoom, TrueArch Technology, Wide Narrow Cone Split Screen, Custom Digital Readout Selection, Custom View Selections, Large Digit View, Selectable Background, Temperature Alarm, Temperature Graph, Triplog, View Preset Keys and an X-Press Menu System.

All 900 Series Units can be upgraded with QuadraBeam PLUS, WeatherSense, CannonLink, InterLink, XMWeather and Navionics Platinum.

Includes:

-Control Head
-Transducer with Temperature Sensor
-Power Cable
-Mount
-Transducer Mounting Hardware
-Unit Cover

Model Display Sonar Power Output Depth GPS
958c HD
Combo
8" Diagonal
480V x 800H
16:9 Color TFT
Dual Beam PLUS
200kHz:20° @ -10db
83kHz:60° @ -10db
8000W(PTP)
1000W(RMS)
1500 ft Yes
959c HD
Combo
8" Diagonal
480V x 800H
16:9 Color TFT
Dual Beam PLUS
200kHz:20° @ -10db
83kHz:60° @ -10db
8000W(PTP)
1000W(RMS)
1500 ft Yes
959c HD
DI Combo
8" Diagonal
480V x 800H
16:9 Color TFT
Dual Beam PLUS
200kHz:25° @ -10db
455kHz:16° @ -10db
Down Imaging
455kHz:75°@ -10db
800kHz:45°@ -10db
4000W(PTP)
500W(RMS)
600 ft.(2D)
350 ft.(DI)
Yes
999c HD
SI Combo
8" Diagonal
480V x 800H
16:9 Color TFT
Dual Beam PLUS
83kHz:60° @ -10db
200kHz:20° @ -10db
HD Side Imaging
455kHz:(2) 86°@ -10db
800kHz: (2) 55°@ -10db
(180° Total coverage)
8000W(PTP)
1000W(RMS)
1500 ft.(2D)
150 ft.(SI)
Yes
999c HD
SI KVD Combo
8" Diagonal
480V x 800H
16:9 Color TFT
Dual Beam PLUS
83kHz:60° @ -10db
200kHz:20° @ -10db
HD Side Imaging
455kHz:(2) 86°@ -10db
800kHz: (2) 55°@ -10db
(180° Total coverage)
8000W(PTP)
1000W(RMS)
1500 ft.(2D)
150 ft.(SI)
Yes

Please Note: This model is not available for order outside of the United States.

Comments: 998 is awesome, clear graphics and great mps. I had a Lowrance hds 7 and sold it to buy the 998 cause the side and down imaging is built in instead of having to buy a seperate box. Love the hummingbirds.

From: Will, AL

Comments: Most amazing piece of electronics to ever see on a boat. Amazing graphics and very good details. Worth every penny!

From: Cody: Tallahassee, FL
